SMT PCB NG OK Buffer Conveyor | Automatic PCB Reject Conveyor

Description

Optimize Your SMT Production Line

The SMT PCB NG/OK Buffer Conveyor is an essential addition to any automated SMT production line. Designed for seamless integration, this conveyor ensures efficient handling of PCB boards post-inspection, reducing downtime and improving workflow.

Reliable Sorting and Buffering

Positioned typically after SPI (Solder Paste Inspection) or AOI (Automated Optical Inspection) systems, the conveyor’s advanced mechanisms automatically sort and buffer “OK” (pass) and “NG” (fail) boards. Based on direct feedback signals from the inspection equipment, it prevents defective boards from moving forward, maintaining the integrity of your production.

Prevent Line Stoppages

Say goodbye to disruptions in your assembly process. The NG/OK Buffer Conveyor ensures that defective boards don’t interrupt the production line, avoiding costly stoppages and keeping operations running smoothly. This innovative system is built to enhance productivity and ensure quality control.

Regarding core operating modes, these buffer transfer units typically support the following three operational logics, controlled via built-in PLC programming: First-In, First-Out (FIFO): During normal production, circuit boards are discharged in the order they arrived, ensuring continuity and consistency in in-line processing times. Last-In, First-Out (LIFO/FILO): When downstream processes are temporarily blocked or special process adjustments are required, the most recently arrived board is temporarily stored at the outermost or topmost position, facilitating quick release or priority manual inspection. Straight-Through / By-pass Mode: When the production line does not require material buffering or process balancing, the equipment can switch to functioning as a standard single-layer belt or roller conveyor, allowing materials to pass directly through.
