Description
Advanced High-Speed Performance
The Juki KE-3020, along with its variants KE-3020V and KE-3020VAL, offers unmatched speed and precision for surface-mount technology (SMT) printed circuit board (PCB) assembly. This modular pick-and-place machine is engineered for accuracy, ensuring a seamless assembly process that meets industrial standards.
Versatile Modular Design
Designed with flexibility in mind, the Juki KE-3020 excels in placing a wide range of tiny electronic components onto PCBs, adapting to diverse production needs. Its modular build enables smooth integration into various assembly lines, providing scalable solutions for growing manufacturing demands.
Reliable and User-Friendly
Reliability and ease of use are hallmarks of the Juki KE-3020. With advanced pick-and-place technology, this machine reduces errors and enhances production efficiency. Perfect for businesses looking to elevate their PCB assembly capabilities.
Key Specifications
- Placement Speed: Up to 17,100 components per hour (CPH) under optimal IPC specs.
- Component Range: Handles tiny 01005 micro-chips up to 74 x 74 mm parts (or 50 x 150 mm).
- Maximum Board Size: Supports large PCBs up to 610 x 560 mm (24″ x 22″).
- Feeder Capacity: Accommodates up to 160 feeder inputs using dual tape setups.
- Accuracy: Laser recognition accuracy of ±0.05 mm and vision recognition accuracy of ±0.03 mm.
Core Features
- Flexible Laser/Vision Head: Uses multi-nozzle laser and vision centering systems to inspect and place diverse parts.
- High-Mix Production: Built for lines that switch frequently between different board layouts and component types.
- Modular Integration: Links smoothly with other high-speed modular mounters (like Juki FX-3 series) to balance production lines.
